Panchsheel Wires Pvt Ltd

Galvanized Wire

OurProducts


PANCHSHEEL IS THE LEADING MANUFACTURERS OF GALVANIZED WIRES IN MUMBAI SINCE 1970. ITS AVAILABLE IN HOT DIP AND ELECTRO GRADE.

AS THE NAME SUGGESTS IN THIS PROCESS the component to be galvanized is dipped in a bath of hot, liquid Zinc. Zinc melts at 419ºC, while Zinc in molten bath usually has a temperature between 440 and 460ºC. The parts to be galvanized are degreased, pickled and fluxed (coated with an adhesive liner), after which they are dipped in the molten Zinc bath. By dipping, the insides, welds and hard to reach corners are well covered. The minimum layer of thickness for the materials used outdoors depending on the thickness of the steel, is 40 GSM or over. This way of Zinc coating offers maximum protection from corrosion.

Galvanized Wire
Galvanized Wire
Galvanized Wire
Galvanized Wire

Product Specification :

Appearance Round/ BRIGHT SHINING
Diameter 4.00mm – 0.13mm
Zinc Coating 40 TO 275 GSM
Coating ZINC COATED ( HOT DIPPED / ELECTRO GAL)
Packing COIL form
Tensile Strength 400 TO 950 N/MM2
or customize to required specifications
Application WIRENETTING/ CHAINLINK/ FENCING/ GABION MESH / POULTRY / CABLE ARMOUR/ REDRAWING/ FINE WIRE MESH / TROLLEYS / WIRE ROPES
