Hot Dip Galvanizing Process
In the hot dip galvanizing process, steel wire is coated with zinc by immersing it in a molten zinc bath maintained at temperatures between 440°C to 460°C.
This process ensures that every surface, including welds and hard-to-reach areas, is uniformly coated, providing maximum protection against corrosion.
With zinc coating thickness ranging from 40 to 275 GSM, our galvanized wires are ideal for both indoor and outdoor applications, offering long-lasting durability even in harsh environments.
- Degreasing
- Pickling
- Fluxing
Product Specifications
| Parameter | Details |
|---|---|
| Appearance | Round / Bright Shining |
| Diameter Range | 0.13 mm to 4.00 mm |
| Zinc Coating | 40 to 275 GSM |
| Type | Hot Dip Galvanized / Electro Galvanized |
| Packing | Coil Form |
| Tensile Strength | 400 to 950 N/mm² |
| Customization | Available as per customer specifications |
Applications
Our galvanized wires are widely used in:
- Wire Netting
- Chain Link Fencing
- Gabion Mesh
- Poultry Mesh
- Cable Armouring
- Redrawing Applications
- Fine Wire Mesh
- Trolleys & Fabrication
- Wire Ropes
Quality Assurance
We manufacture galvanized wires using high-quality raw materials and strict quality control processes to ensure:
- Uniform zinc coating
- High tensile strength
- Long-lasting corrosion resistance
- Reliable performance in outdoor environments
Custom Manufacturing Available
We provide customized galvanized wire solutions based on:
- Diameter and coating thickness
- Tensile strength requirements
- Application-specific needs
